Digital Protractor

FEATURES
2. Large LCD display reads upright
at any angle.
3. With backlight and buzzer
4. Degree & slope conversion,
5. data hold.
6. Calibrate button
7. Runs on by 3 pcs CR2032 3V batteries

Order Code

Range

Resolution

Repeatability

Remarks

SRDP200

4*90

 0.1

0.1

Working Temp.

Relative Humidity.

0ºC-40ºC

40%-80%

Packing list

MEAS.

QTY.

N.W./G.W.

QTY./Inner Box

63*18*23.5cm

50pcs

15.5/16.6Kgs

 10pcs


Single Packing:Paper box

Digital Protractor

FEATURES
1. SRDP200P and SRDP200V have magnet in measuring faces which can be easy attracted to the object to be measured.
2. Large LCD display reads upright
at any angle.
3. With backlight and buzzer
4. Degree & slope conversion,
5. data hold.
6. Calibrate button
7. Runs on by 3 pcs CR2032 3V batteries

Order Code

Range

Resolution

Repeatability

Remarks

SRDP200P

4*90

 0.1

0.1

Working Temp.

Relative Humidity.

0ºC-40ºC

40%-80%

Packing list

MEAS.

QTY.

N.W./G.W.

QTY./Inner Box

63*18*23.5cm

50pcs

25.9/27Kgs

 10pcs

Digital Protractor

FEATURES
1. SRDP200P and SRDP200V have magnet in measuring faces which can be easy attracted to the object to be measured.
2. Large LCD display reads upright
at any angle.
3. With backlight and buzzer
4. Degree & slope conversion,
5. data hold.
6. Calibrate button
7. Runs on by 3 pcs CR2032 3V batteries

Order Code

Range

Resolution

Repeatability

Remarks

SRDP200V

4*90

 0.1

0.1

Working Temp.

Relative Humidity.

0ºC-40ºC

40%-80%

Packing list

MEAS.

QTY.

N.W./G.W.

QTY./Inner Box

63*18*23.5cm

50pcs

25.9/27Kgs

 10pcs

FEATURES
1. Magnetic base securely attaches
gauge to any metal surface
2. Large LCD display reads upright
at any angle.
3. With backlight and buzzer
4. Degree,mm/m and slope conversion,
5. data hold.
6. Calibrate button
7. Auto power off
8. Runs on by 3 pcs CR2032 batteries

Order Code

Range

Resolution

Basic Length

Remarks

SRDP300

4*90

 0.05/0.01%/mm/m

  150mm

Packing list

MEAS.

QTY.

N.W./G.W.

QTY./Inner Box

63*18*23.5cm

50pcs

25.9/27Kgs

 10pcs

Digital Protractor

FEATURES:

1) with a Big LCD Screen
2) with plastic shell
3) with Aluminum framework for measuring surface
4) with Absolute/relative/slope/measurement model
5) with a power supply of 3V CR2032 Lithium battery

Order Code

Range

Resolution

Accuracy

Remarks

SRDP005

4*90

 0.1

0~90 0.1, others 0.2

Packing:

Unit size of product: 152*33.8*60mm

Unit weight of product: 297g+/-1.5g

Package

color box

Aluminum case

Accessory

3V CR2032 Lithium battery, Bubble bag, Instruction, Leather pouch

3V CR2032 Lithium battery, Instruction, Desiccant

Size of unit Package

160*70*74mm

175*88*80mm

Weight of unit Package

430g

560g

Digital Protractor with magnet

FEATURES:

1) with a magnetism bottom
2) with a Big LCD Screen
3) with plastic shell
4) with Aluminum framework for measuring surface
5) with Absolute/relative/slope/measurement model
6) with a power supply of 3V CR2032 Lithium battery

Order Code

Range

Resolution

Accuracy

Remarks

SRDP006 (with magnet)

4*90

 0.1

0~90 0.1, others 0.2

Packing:

Unit size of product: 151.2*33.8*60mm

Unit weight of product: 294g+/-1.5g

Package

color box

Aluminum case

Accessory

3V CR2032 Lithium battery, Bubble bag, Instruction, Leather pouch

3V CR2032 Lithium battery, Instruction, Desiccant

Size of unit Package

160*70*74mm

175*88*80mm

Weight of unit Package

400g

550g

Digital Level Module

FEATURES:


1) with a Big LCD Screen
2) with stainless steel stand
3) with plastic shell
4) with Absolute/relative/slope/measurement model
5) with a power supply of 3V CR2032 Lithium battery

Order Code

Range

Resolution

Accuracy

Remarks

SRDP007

4*90

 0.1

0~90 0.1, others 0.2

Packing:

Package: Plain box

Accessory: 3V CR2032 Lithium battery, Bubble bag, Instruction

Unit size of package: 182*31*60mm

SRPB001  Digital Protractor / Inclinometer

Note: We have three type for this model: SRPB001 (plastic case), SRPB001 (Zinc Alloy case) and SRPB001 (three magnets).

FEATURES:
1. 360 degree full measure;

2. When inclinometer inversion angle LCD readout will automatically flip up for easy reading;

3. Precision measurement of the mechanical structure of stainless steel;

4. May not require any special tools and equipment for the new correction;

5. Multi-purpose measurement tools, protractor, ruler and level inclinometer triple.

Technical Data:

Order Code

Range

Resolution

Accuracy

Working Temperature

Working Current

SRPB001 4*90 (0-360) 0.05 0.2

0~45C

<100uA

Product Details:

Digital Protractor / Bevel Box

FEATURES
1. Measuring plane containing disk magnet can stick to the surface to be measured;

2. Works great for miter saws and table saws;
3. Sets the angel of the jointer fences and band saw tables;

4. Machine cone bevel measuring and measuring in processing;

5. Telecommunication industry, Radar antenna calibration, Elevation measuring for secondary planet antenna and television receiver;

6. Automobile: four-wheel location, pavement control and leveling for construction vehicles;

Order No. Range Resolution Repeatability Working current Remarks
SRPB002 180(0-360) 0.1 0.1 <100uA Water proof: IP54

Packing:

Unit size of product: 50.8*33*50.8mm

Unit weight of product: 118g+/-1.5g

Package

Color box

Accessory

Instruction, Leather pouch, 3V CR2032 Lithium battery

Size of unit Package

70*45*95mm

Weight of unit Package

176g

Digital Protractor / Bevel Box

FEATURES
1. Measuring plane containing disk magnet can stick to the surface to be measured;

2. Works great for miter saws and table saws;
3. Sets the angel of the jointer fences and band saw tables;

4. Machine cone bevel measuring and measuring in processing;

5. Telecommunication industry, Radar antenna calibration, Elevation measuring for secondary planet antenna and television receiver;

6. Automobile: four-wheel location, pavement control and leveling for construction vehicles;

Order No. Range Resolution Repeatability Working current Remarks
SRPB003 180(0-360) 0.1 0.1 <100uA Water proof: IP54

Packing:

Unit size of product: 50.8*33*50.8mm

Unit weight of product: 172g+/-1.5g

Package

Color box

Accessory

Instruction, Leather pouch, 3V CR2032 Lithium battery

Size of unit Package

70*46*95mm

Weight of unit Package

230g

Digital Protractor / Bevel Box

FEATURES
1. Measuring plane containing disk magnet can stick to the surface to be measured;

2. Works great for miter saws and table saws;
3. Sets the angel of the jointer fences and band saw tables;

4. Machine cone bevel measuring and measuring in processing;

5. Telecommunication industry, Radar antenna calibration, Elevation measuring for secondary planet antenna and television receiver;

6. Automobile: four-wheel location, pavement control and leveling for construction vehicles;

Order No. Range Resolution Repeatability Working current Remarks
SRPB004 180(0-360) 0.1 0.1 <100uA Water proof: IP54

Packing:

Unit size of product: 50.8*33*50.8mm

Unit weight of product: 118g+/-1.5g

Package

Color box

Accessory

Instruction, Leather pouch, 3V CR2032 Lithium battery

Size of unit Package

70*45*95mm

Weight of unit Package

176g

Digital Protractor / Bevel Box

FEATURES
1. Measuring plane containing disk magnet can stick to the surface to be measured;

2. Works great for miter saws and table saws;
3. Sets the angel of the jointer fences and band saw tables;

4. Machine cone bevel measuring and measuring in processing;

5. Telecommunication industry, Radar antenna calibration, Elevation measuring for secondary planet antenna and television receiver;

6. Automobile: four-wheel location, pavement control and leveling for construction vehicles;

Order No. Range Resolution Repeatability Working current Remarks
SRPB005 180(0-360) 0.1 0.1 <100uA Water proof: IP54

Packing:

Unit size of product: 50.8*33*50.8mm

Unit weight of product: 172g+/-1.5g

Package

Color box

Accessory

Instruction, Leather pouch, 3V CR2032 Lithium battery

Size of unit Package

70*45*95mm

Weight of unit Package

230g

Digital Protractor / Bevel Box

FEATURES
1. Measuring plane containing disk magnet can stick to the surface to be measured;

2. Works great for miter saws and table saws;
3. Sets the angel of the jointer fences and band saw tables;

4. Machine cone bevel measuring and measuring in processing;

5. Telecommunication industry, Radar antenna calibration, Elevation measuring for secondary planet antenna and television receiver;

6. Automobile: four-wheel location, pavement control and leveling for construction vehicles;

Order No. Range Resolution Repeatability Working current Remarks
SRPB006 180(0-360) 0.1 0.1 <100uA Water proof: IP54

Packing:

Unit size of product: 50.8*33*64mm

Unit weight of product: 133g+/-1.5g

Package

Color box

Accessory

Instruction, Leather pouch, 3V CR2032 Lithium battery

Size of unit Package

70*45*95mm

Weight of unit Package

191g

Digital Protractor / Bevel Box

FEATURES
1. Measuring plane containing disk magnet can stick to the surface to be measured;

2. Works great for miter saws and table saws;
3. Sets the angel of the jointer fences and band saw tables;

4. Machine cone bevel measuring and measuring in processing;

5. Telecommunication industry, Radar antenna calibration, Elevation measuring for secondary planet antenna and television receiver;

6. Automobile: four-wheel location, pavement control and leveling for construction vehicles;

Order No. Range Resolution Repeatability Working current Remarks
SRPB007 180(0-360) 0.1 0.1 <100uA Water proof: IP54

Packing:

Unit size of product: 50.8*33*64mm

Unit weight of product: 185g+/-1.5g

Package

Color box

Accessory

Instruction, Leather pouch, 3V CR2032 Lithium battery

Size of unit Package

70*45*95mm

Weight of unit Package

243g

Mini Digital Protractor / Mini Digital Inclinometer Protractor Bevel Box

FEATURES
1. Magnetic base securely attaches gauge to any metal surface 2. Large LCD display reads upright at any angle.
3. Degree & slope conversion, 4. data hold. 5. Calibrate button 6. Runs on by 3 pcs CR2032 3V batteries

Order Code

Range

Resolution

Repeatability

Remarks

SRPB100

4*90

 0.1

 0.1

Working Temp.

Relative Humidity.

0ºC-40ºC

40%-80%

Packing list

MEAS.

QTY.

N.W./G.W.

QTY./Inner Box

39*24*23cm

120pcs

15.6/16.5Kgs

 30pcs

Mini Digital Protractor W/ Stainess Steel Basic


Easy set the angle of your jointer fences and band saw table

FEATURES
1) Magnetic base securely attaches gauge to any metal surface
2) Large LCD display reads upright at any angle
3) Degree & slope conversion,
4) Data hold.
5) Calibrate button
6) Runs on by 3 pcs CR2032 3V batteries

Order No. Range Resolution Working Temp. Remarks
SRPB111 4x90 0.1 0-40ºC

Mini Digital Protractor

FEATURE
1. Platform monitoring
2. Drainage angles and run-off slopes
3. Grader and tractor work alignment
4. Setting blade angle of Circular Saws
5. Tool setting on Lathes
6. Setting work piece angle for milling
7. Setting blade angle of Miter Saws
8. Check drill press table setting, table saw, jointer table, band saw, jointer fence or band saw table

Order Code

Range

Resolution

Repeatability

Remarks

SRPB120

4*90

 0.1/ 0.01%

 0.1

Working Temp.

Relative Humidity.

0ºC-40ºC

40%-80%

Packing list

MEAS.

QTY.

N.W./G.W.

QTY./Inner Box

39*24*23cm

120pcs

15.6/16.5Kgs

 30pcs

 ( If you need user manual or E-catalogue for above meters, please ask for at: xiushunjie@gmail.com )
