SRT12A |
SRT12A
Non-Contact AC Voltage Detectors
SPECIFICATIONS
|
Functions / Features |
SRT12A
|
|
Voltage Sensitivity |
90 ~ 1000VAC |
|
Bandwidth |
50/60Hz |
|
Normal Indicators |
Beep and flashing LED indicate the
presence of voltage |
|
Battery Indication |
The LED will not flash if the battery is
less than 2V. The beep sounds will still
have but may be weaker. |
|
Silent Indicators |
LED flashing only, it could save battery |
|
Auto Power Off |
Around 30 minutes |
|
NCV Detection By |
Hold-on to On/Off Button |
GENERAL CHARACTERISTICS
|
Power |
1.5V Battery (AAA) x 2 |
|
Product Color |
Red and Grey |
|
Product Net Weight |
49g |
|
Product Size |
150 x 109mm |
|
Standard Accessories |
Batteries, English Manual |
|
Standard Individual Packing |
Blister |
|
Standard Quantity Per Carton |
100 pcs |
|
Standard Carton Measurement |
485 x 255 x 470mm
(0.058 CBM Per
Standard Carton) |
|
Standard Carton Gross Weight |
13kg |
|
|
SRT12B |
SRT12B
Non-Contact AC Voltage Detectors
SPECIFICATIONS
|
Functions / Features |
SRT12B |
|
Voltage Sensitivity |
90 ~ 1000VAC |
|
Bandwidth |
50/60Hz |
|
Normal Indicators |
Beep and flashing LED indicate the presence of voltage
(Beep
Indicators: cancelable) |
|
Battery Indication |
The LED will not flash if the battery is less than 2V. The beep
sounds will still have but may be weaker. |
|
Silent Indicators |
LED flashing only, it could save battery |
|
Auto Power Off |
Around 3 minutes |
|
NCV Detection By |
Auto Sense |
GENERAL CHARACTERISTICS
|
Power |
1.5V Battery (AAA) x 2 |
|
Product Color |
Red and Grey |
|
Product Net Weight |
49g |
|
Product Size |
150 x 109mm |
|
Standard Accessories |
Batteries, English Manual |
|
Standard Individual Packing |
Blister |
|
Standard Quantity Per Carton |
100 pcs |
|
Standard Carton Measurement |
485 x 255 x 470mm
(0.058 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
13kg |
|
|
SRT15C
|
SRT15C
Multifunction Voltage Testers
(Waterproof Type)
SPECIFICATIONS
|
Functions/ Features |
SRT15C
|
|
Voltage LED Steps (AC/D) |
12V: between 0 to 12V LED will illuminate
24V: between 19V ± 2V LED will illuminate
50V: between 48V ± 6V LED will illuminate
120V: between 110V ± 20V LED will illuminate
230V: between 200V ± 20V LED will illuminate
400V: between 340V ± 30V LED will illuminate
690V: between 520V ± 30V LED will illuminate |
|
Continuity Test |
Range 0 to 100kΩ. The continuity LED will
illuminate
and buzzer will sound. |
|
Phase Rotation Test |
50Hz to 60Hz |
|
Range Selection |
Automatic |
|
Polarity Detection |
Positive & Negative |
|
Low Battery Display |
Short circuit two leads, LED and beeper do not
on that means
the battery is low |
|
Torch |
Yes |
|
Single Lead (L2) Voltage
Detection |
It is intended only as a quick check. 100V to
690V;
50Hz to 400Hz |
|
Short Circuit Detection |
Yes |
|
LCD display (AC/DC) |
24V to 690V: ±(3%+5) |
GENERAL CHARACTERISTICS
|
Power |
1.5V Battery (AAA) x 2 |
|
LCD Size |
23 x 12mm |
|
Product Color |
Red and Grey |
|
Product Net Weight |
210g |
|
Product Size |
275 x 51 x 30mm |
|
Standard Accessories |
Batteries, English Manual |
|
Standard Individual Packing |
Blister |
|
Standard Quantity Per Carton |
30pcs |
|
Standard Carton Measurement |
440 x 295 x 455mm (0.079CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
17kg |
|
|
SRT33A |
SRT33A Palm-Size Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
400mV/4V/40V/400V/500V |
±(0.8%+1) |
|
AC Voltage |
4V/40V/400V/500V |
±(1.2%+3) |
|
DC Current |
400mA/4000mA/40mA/400mA/4A/10A |
±(1%+2) |
|
AC Current |
400mA/4000mA/40mA/400mA/4A/10A |
±(1.5%+5) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
±(1%+2) |
|
Special Functions |
|
|
|
Auto Ranging |
|
Yes |
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Transistor |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for DC
Voltage Measurement |
Around 10MΩ |
|
|
Max. Display |
3999 |
|
GENERAL CHARACTERISTICS
|
Power |
1.5V Battery (AAA x 2) |
|
LCD Size |
48 x 16mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
156g |
|
Product Size |
130 x 73.5 x 35mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Holster |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
60pcs |
|
Standard Carton Measurement |
490 x 356 x 315mm
(Around 0.055 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
18kg |
|
|
SRT33B |
SRT33B Palm-Size Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2000mV/20V/200V/500V |
±(0.5%+2) |
|
AC Voltage |
200V/500V |
±(1.2%+10) |
|
DC Current |
200mA/200mA/10A |
±(1%+2) |
|
Resistance |
200Ω/2000Ω/20kΩ/200kΩ/20MΩ |
±(0.8%+2) |
|
Special Functions |
|
|
|
Battery Test |
1.5V/9V/12V |
±(2.5%+2) |
|
Diode |
|
Yes |
|
Data Hold |
|
Yes |
|
Display Backlight |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for DC
Voltage Measurement |
Around 10MΩ |
Yes |
|
Max. Display |
1999 |
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
48 x 16mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
156g |
|
Product Size |
130 x 73.5 x 35mm |
|
Standard Accessories |
Test Lead, Battery, English
Manual, Holster |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
60pcs |
|
Standard Carton Measurement |
490 x 356 x 315mm
(Around 0.055 CBM Per Standard
Carton) |
|
Standard Carton Gross Weight |
18kg |
|
|
SRT33C |
SRT33C Palm-Size Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2000mV/20V/200V/500V |
±(0.5%+2) |
|
AC Voltage |
200V/500V |
±(1.2%+10) |
|
DC Current |
2000mA/20mA/200mA/10A |
±(1%+2) |
|
Resistance |
200Ω/2000Ω/20kΩ/200kΩ/20MΩ |
±(0.8%+2) |
|
Temperature (°C) |
-40°C ~ 1000°C |
±(1%+3) |
|
Temperature (°F) |
-40°F ~ 1832°F |
±(1%+4) |
|
Special
Functions |
|
|
|
Diode |
|
Yes |
|
Continuity
Buzzer |
|
Yes |
|
Data Hold |
|
Yes |
|
Display
Backlight |
|
Yes |
|
Low Battery
Display |
|
Yes |
|
Input Impedance
for DC
Voltage
Measurement |
Around 10MΩ |
Yes |
|
Max. Display |
1999 |
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery
(6F22) |
|
LCD Size |
48 x 16mm |
|
Product Colour |
Red and Grey |
|
Product Net
Weight |
Around 156g |
|
Product Size |
130 x 73.5 x
35mm |
|
Standard
Accessories |
Test Lead,
Battery, English
Manual,
Point Contact
Temperature
Probe, Holster |
|
Standard
Individual
Packing |
Gift Box |
|
Standard
Quantity Per
Carton |
60pcs |
|
Standard Carton
Measurement |
490 x 356 x
315mm
(Around 0.055
CBM Per Standard
Carton) |
|
Standard Carton
Gross Weight |
20kg |
|
|
SRT33D |
SRT33D Palm-Size Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2000mV/20V/200V/500V |
±(0.5%+2) |
|
AC Voltage |
200V/500V |
±(1.2%+10) |
|
DC Current |
2000mA/20mA/200mA/10A |
±(1%+2) |
|
Resistance |
200Ω/2000Ω/20kΩ/200kΩ/20MΩ/200MΩ |
±(0.8%+2) |
|
Special Functions |
|
|
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Square Wave Output |
|
Yes |
|
Data Hold |
|
Yes |
|
Display Backlight |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for DC
Voltage Measurement |
Around 10MΩ |
Yes |
|
Max. Display |
1999 |
Yes |
GENERAL
CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
48 x 16mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
156g |
|
Product Size |
130 x 73.5 x 35mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Holster |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
60pcs |
|
Standard Carton Measurement |
490 x 356 x 315mm
(Around 0.055 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
18kg |
|
|
SRT136B |
SRT136B Automatic Range Digital Multimeter
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
400mV/4V/40V/400V/500V |
±(0.8%+1) |
|
AC Voltage |
400mV/4V/40V/400V/500V |
±(1.2%+3) |
|
DC Current |
400uA/4mA/40mA/400mA/4A/10A |
±(1.0%+2) |
|
AC Current |
400uA/4mA/40mA/400mA/4A/10A |
±(1.2%+5) |
|
Capacitance |
4nF/40nF/400nF/4uF/40uF/100uF |
±(4.0%+3) |
|
Frequency |
10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz |
±(0.5%+3) |
|
Resistance |
400Ω/4000Ω/40kΩ/400kΩ/4MΩ/40MΩ |
±(1.0%+2) |
|
Special Functions |
|
|
|
Duty
Cycle |
0.1%~99.9% |
Yes |
|
Diode |
Yes |
|
|
Continuity Buzzer |
Yes |
|
|
Auto Power Off |
Yes |
|
|
Low Battery Display |
Yes |
|
|
Input Impedance for DC Voltage Measurement |
10MΩ |
|
|
Data Hold |
Yes |
|
|
Max. Display |
3999 |
|
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
18x49mm |
|
Product Colour |
SRT136B - Grey, Holster - Red |
|
Product Net Weight |
200g (including holster) |
|
Product Size |
72 x 137 x 35mm |
|
Standard Accessories |
Test Lead, Battery, English Manual |
|
Standard Packing |
Gift Box |
|
Standard Quantity Per Carton |
60 pcs |
|
Standard Carton Measurement |
540 x 310 x 350mm |
|
Standard Carton Gross Weight |
20kg |
|
|
SRT39A |
SRT39A Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
20µA/200µA/2mA/20mA/200mA/10A |
±(0.8%+1) |
|
AC Current |
200µA/20mA/200mA/10A |
±(1%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/200MΩ |
±(0.8%+1) |
|
Capacitance |
2µF |
±(4%+3) |
|
Special Functions |
|
|
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Transistor |
|
Yes |
|
Data Hold |
|
Yes |
|
Sleep Mode |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for
DC Voltage Measurement |
Around 10MΩ |
Yes |
|
Max. Display |
1999 |
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
61 x 32mm |
|
Product Colour |
Grey Holster-Red |
|
Product Net Weight |
310g (Including Holster) |
|
Product Size |
172 x 83 x 38mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Holster |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
40pcs |
|
Standard Carton Measurement |
598 x 418 x 340mm (0.085CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
21kg |
|
|
SRT39C |
SRT39C Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
2mA/200mA/20A |
±(0.8%+1) |
|
AC Current |
2mA/200mA/20A |
±(1%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/2MΩ/20MΩ |
±(0.8%+10) |
|
Capacitance |
2nF/200nF/20µF |
±(4%+3) |
|
Temperature (°C) |
-40°C ~ 1000°C |
±(2%+8) |
|
Frequency |
2kHz/20kHz |
±(1.5%+5) |
|
Special Functions |
|
|
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Transistor |
|
Yes |
|
Data Hold |
|
Yes |
|
Sleep Mode |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for
DC Voltage Measurement |
Around 10MΩ |
Yes |
|
Max. Display |
|
1999 |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
61 x 32mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
310g (Including Holster) |
|
Product Size |
172 x 83 x 38mm |
|
Standard Accessories |
Test Lead, Battery, English Manual,
Point Contact Temperature Probe, Holster |
|
Optional Accessories* |
Clip-On Test Lead Light , Built-In Test Lead Light , Built-In
Test Lead Light Plus |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
40pcs |
|
Standard Carton Measurement |
598 x 418 x 340mm (0.085 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
22kg |
|
|
SRT39E |
SRT39E Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.05%+3) |
|
AC Voltage |
2V/20V/200V/750V |
±(0.5%+10) |
|
DC Current |
2mA/200mA/20A |
±(0.5%+5) |
|
AC Current |
2mA/200mA/20A |
±(0.8%+5) |
|
Resistance |
200Ω/2kΩ/20kΩ/2MΩ/20MΩ |
±(0.3%+1) |
|
Capacitance |
2nF/20nF/200nF/20µF |
±(4%+3) |
|
Frequency |
2kHz/20kHz |
±(1.5%+5) |
|
Special Functions |
|
|
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Transistor |
|
Yes |
|
Data Hold |
|
Yes |
|
Sleep Mode |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for
DC Voltage Measurement |
Around 10MΩ |
Yes |
|
Max. Display |
|
19999 |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
61 x 32mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
310g (Including Holster) |
|
Product Size |
172 x 83 x 38mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Holster |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
40pcs |
|
Standard Carton Measurement |
598 x 418 x 340mm (0.082CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
22kg |
|
|
SRT51 |
SRT51 Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
200mV/2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
20mA/200mA/2mA/20mA/200mA/2A/10A |
±(0.8%+1) |
|
AC Current |
200mA/2mA/20mA/200mA/2A/10A |
±(1%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ |
±(0.8%+1) |
|
Special Functions |
|
|
|
Fused 10A Range |
Yes |
|
|
Transistor |
Yes |
|
|
Diode |
Yes |
|
|
Continuity Buzzer |
Yes |
|
|
Sleep Mode |
Yes |
|
|
Low Battery Display |
Yes |
|
|
Input Impedance for DC Voltage Measurement |
10MΩ |
|
|
Max. Display |
1999 |
|
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
33x65mm |
|
Product Colour |
SRT51 - Grey, Holster - Red |
|
Product Net Weight |
560g (including holster) |
|
Product Size |
190 x 88 x 34mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Holster |
|
Optional Accessories* |
Clip-On Test Lead Light, Built-In Test Lead Light , Built-In
Test Lead Light Plus |
|
Standard Packing |
Gift Box |
|
Standard Quantity Per Carton |
20 pcs |
|
Standard Carton Measurement |
535 x 362 x 385mm |
|
Standard Carton Gross Weight |
17kg |
|
|
SRT52 |
SRT52 Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
200mV/2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
2mA/20mA/200mA/20A |
±(0.8%+1) |
|
AC Current |
2mA/20mA/200mA/20A |
±(1%+3) |
|
Capacitance |
2nF/20nF/200nF/2mF/20mF |
±(4%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ |
±(0.8%+1) |
|
Special Functions |
|
|
|
Transistor |
Yes |
|
|
Diode |
Yes |
|
|
Continuity Buzzer |
Yes |
|
|
Low Battery Display |
Yes |
|
|
Input Impedance for DC Voltage Measurement |
10MΩ |
|
|
Max. Display |
1999 |
|
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
33x65mm |
|
Product Colour |
SRT52 - Grey, Holster - Red |
|
Product Net Weight |
560g (including holster) |
|
Product Size |
190 x 88 x 34mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Holster |
|
Optional Accessories* |
Clip-On Test Lead Light, Built-In Test Lead Light, Built-In Test
Lead Light Plus |
|
Standard Packing |
Gift Box |
|
Standard Quantity Per Carton |
20 pcs |
|
Standard Carton Measurement |
535 x 362 x 385mm |
|
Standard Carton Gross Weight |
17kg |
|
|
SRT53 |
SRT53 Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
200mV/2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
2mA/20mA/200mA/20A |
±(0.8%+1) |
|
AC Current |
20mA/200mA/20A |
±(1%+3) |
|
Capacitance |
2nF/20nF/200nF/2mF/20mF |
±(4%+3) |
|
Temperature (oC) |
-20oC~1000oC |
±(1%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ |
±(0.8%+1) |
|
Special Functions |
|
|
|
Transistor |
Yes |
|
|
Diode |
Yes |
|
|
Continuity Buzzer |
Yes |
|
|
Sleep Mode |
Yes |
|
|
Low Battery Display |
Yes |
|
|
Input Impedance for DC Voltage Measurement |
10MΩ |
|
|
Max. Display |
1999 |
|
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
33x65mm |
|
Product Colour |
SRT53 - Grey, Holster - Red |
|
Product Net Weight |
580g (including holster) |
|
Product Size |
190 x 88 x 34mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Point Contact Temperature
Probe, Holster |
|
Optional Accessories* |
Clip-On Test Lead Light, Built-In Test Lead Light, Built-In Test
Lead Light Plus |
|
Standard Packing |
Gift Box |
|
Standard Quantity Per Carton |
20 pcs |
|
Standard Carton Measurement |
535 x 362 x 385mm |
|
Standard Carton Gross Weight |
17.6kg |
|
|
SRT54 |
SRT54 Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
2mA/20mA/200mA/20A |
±(0.8%+1) |
|
AC Current |
20mA/200mA/20A |
±(1%+3) |
|
Capacitance |
2nF/20nF/200nF/2mF/20mF |
±(4%+3) |
|
Frequency |
2kHz/20kHz |
±(1.5%+5) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ |
±(0.8%+1) |
|
Special Functions |
|
|
|
Transistor |
Yes |
|
|
Diode |
Yes |
|
|
Continuity Buzzer |
Yes |
|
|
Sleep Mode |
Yes |
|
|
Low Battery Display |
Yes |
|
|
Input Impedance for DC Voltage Measurement |
10MΩ |
|
|
Max. Display |
1999 |
|
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
33x65mm |
|
Product Colour |
SRT54 - Grey, Holster - Red |
|
Product Net Weight |
580g (including holster) |
|
Product Size |
190 x 88 x 34mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Holster |
|
Optional Accessories* |
Clip-On Test Lead Light, Built-In Test Lead Light, Built-In Test
Lead Light Plus |
|
Standard Packing |
Gift Box |
|
Standard Quantity Per Carton |
20 pcs |
|
Standard Carton Measurement |
535 x 362 x 385mm |
|
Standard Carton Gross Weight |
17.4kg |
|
|
SRT55 |
SRT55 Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
2mA/20mA/200mA/20A |
±(0.8%+1) |
|
AC Current |
20mA/200mA/20A |
±(1%+3) |
|
Capacitance |
2nF/20nF/200nF/2mF/20mF |
±(4%+3) |
|
Frequency |
20kHz |
±(1.5%+5) |
|
Temperature (oC) |
-20oC~1000oC |
±(1%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ |
±(0.8%+1) |
|
Special Functions |
|
|
|
Transistor |
Yes |
|
|
Diode |
Yes |
|
|
Continuity Buzzer |
Yes |
|
|
Sleep Mode |
Yes |
|
|
Low Battery Display |
Yes |
|
|
Input Impedance for DC Voltage Measurement |
10MΩ |
|
|
Max. Display |
1999 |
|
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
33x65mm |
|
Product Colour |
SRT55 - Grey, Holster - Red |
|
Product Net Weight |
580g (including holster) |
|
Product Size |
190 x 88 x 34mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Point Contact Temperature
Probe, Holster |
|
Optional Accessories* |
Clip-On Test Lead Light, Built-In Test Lead Light, Built-In Test
Lead Light Plus |
|
Standard Packing |
Gift Box |
|
Standard Quantity Per Carton |
20 pcs |
|
Standard Carton Measurement |
535 x 362 x 385mm |
|
Standard Carton Gross Weight |
17.6kg |
|
|
SRT56 |
SRT56 Standard Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.05%+3) |
|
AC Voltage |
200mV/2V/20V/200V/750V |
±(0.5%+10) |
|
DC Current |
2mA/20mA/200mA/20A |
±(0.5%+5) |
|
AC Current |
2mA/200mA/20A |
±(0.8%+10) |
|
Capacitance |
20nF/200nF/2mF/20mF |
±(4%+20) |
|
Frequency |
20kHz |
±(1.5%+5) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ |
±(0.3%+1) |
|
Special Functions |
|
|
|
Transistor |
Yes |
|
|
Diode |
Yes |
|
|
Data Hold |
Yes |
|
|
Continuity Buzzer |
Yes |
|
|
Sleep Mode |
Yes |
|
|
Low Battery Display |
Yes |
|
|
Input Impedance for DC Voltage Measurement |
10MΩ |
|
|
Max. Display |
19999 |
|
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
33x65mm |
|
Product Colour |
SRT56 - Grey, Holster - Red |
|
Product Net Weight |
540g (including holster) |
|
Product Size |
190 x 88 x 34mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Point Contact Temperature
Probe, Holster |
|
Optional Accessories* |
Clip-On Test Lead Light, Built-In Test Lead Light, Built-In Test
Lead Light Plus |
|
Standard Packing |
Gift Box |
|
Standard Quantity Per Carton |
20 pcs |
|
Standard Carton Measurement |
535 x 362 x 385mm |
|
Standard Carton Gross Weight |
17.4kg |
|
|
SRT58A |
SRT58A Modern Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
AC Voltage |
2V/20V/200V/750V |
±(0.8%+3) |
|
DC Current |
20mA/2mA/20mA/200mA/20A |
±(0.8%+1) |
|
AC Current |
2mA/200mA/20A |
±(1%+3) |
|
Resistance |
200Ω/2kΩ/20kΩ/2MΩ/20MΩ/200MΩ |
±(0.8%+1) |
|
Capacitance |
2nF/200nF/100mF |
±(4%+3) |
|
Special Functions |
|
|
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Transistor |
|
Yes |
|
Data Hold |
|
Yes |
|
Full Icon Display |
|
Yes |
|
Sleep Mode |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for DC
Voltage Measurement |
Around 10MΩ |
Yes |
|
Max Display |
1999 |
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
60 x 54mm |
|
Product Colour |
SRT58A - Grey, Holster - Red |
|
Product Net Weight |
350g (including holster) |
|
Product Size |
179 x 88 x 39mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Multi-Purpose Socket,
Holster |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
40pcs |
|
Standard Carton Measurement |
598 x 418 x 340mm (0.085 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
27kg |
|
SRT58E |
SRT58E Modern Digital Multimeters
SPECIFICATIONS
|
Specifications |
Range |
|
|
Model |
|
SRT58E |
|
DC Voltage (V) |
200mV20V/200V/1000V |
|
|
200mV/2V/20V/200V/1000V |
+/-(0.05%+3) |
|
AC Voltage (V) |
2V/200V/1000V |
|
|
2V/20V/200V/1000V |
+/-(0.5%+10) |
|
DC Current (A) |
2mA/20mA/20A |
+/-(0.5%+5) |
|
AC Current (A) |
2mA/20mA/20A |
|
|
20mA/200mA/20A |
+/-(0.8%+10) |
|
Resistance (Ω) |
200Ω/2KΩ/200KΩ/2MΩ/20MΩ |
|
|
200Ω/2KΩ/20KΩ/2MΩ/200MΩ |
+/-(0.5%+10) |
|
Capacitance (F) |
20nF/200nF/2μF/100μF |
|
|
2nF/20nF/2μF/20μF |
+/-(3%+4) |
|
Inductance (H) |
2mH/20mH/200mH/20H |
|
|
Frequency (Hz) |
20KHz |
+/-(1.5%+5) |
|
Temperature (°C) |
-40 °C - 1000°C |
+/-(1%+30) |
|
Features |
|
Display Count |
|
2000 |
|
Manual Range |
|
YES |
|
Diode |
|
YES |
|
Transistor |
|
YES |
|
Auto Power Off |
|
YES |
|
Continuity Buzzer |
|
YES |
|
Data Hold |
|
YES |
|
Low Battery Indication |
|
YES |
|
Full Icon Display |
|
YES |
|
Input Impedance for DCV |
Around 10MΩ |
YES |
|
Test Lead Connection Indications |
|
YES |
|
General Characteristic |
|
Power |
9V Battery（6F22)
|
|
LCD Size |
60mm*54mm |
|
Product Color |
Red and Grey |
|
Product Net Weight |
350g （Including
holster) |
|
Product Size |
179mm*88mm*39mm |
|
Standard Accessories |
Test Lead,Holster, Muli-Purpose Socket,
Point Contact Temperature Probe |
|
Standard Individual Packing |
Gift Box, English Manual |
|
Standard Quantity Per Carton |
40 Pcs |
|
Standard Carton Measurement |
598mm×418mm×340mm (0.085 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
27 Kg |
|
|
SRT61A |
SRT61A Modern Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
400mV/4V/40V/400V/1000V |
±(0.5%+1) |
|
AC Voltage |
400mV/4V/40V/400V/750V |
±(1.0%+3) |
|
AC Current |
400mA/4000mA/40mA/400mA/4A/10A |
±(1.2%+5) |
|
DC Current |
400mA/4000mA/40mA/400mA/4A/10A |
±(1.0%+2) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
±(1.0%+2) |
|
Capacitance |
40nF/400nF/4mF/40mF400mF/4000mF |
±(3.0%+5) |
|
Frequency |
10Hz-10MHz |
±(0.1%+4) |
|
Frequency Response |
0 |
45~400Hz |
|
Duty Cycle |
0.1%~99.9% |
Yes |
|
Special Functions |
|
|
|
Auto/Manual Ranging |
|
Yes |
|
Diode |
|
Yes |
|
EF Function |
|
Yes |
|
Audion |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Data Hold |
|
Yes |
|
Max/Min Mode |
|
Yes |
|
Display Backlight |
|
Yes |
|
REL |
|
Yes |
|
Analogue Bar Graph |
41 |
Yes |
|
Input Protection |
|
Yes |
|
Input Impedance for DC Voltage Measurement |
Around 10MΩ |
Yes |
|
Low Battery Display |
≤7.5V |
Yes |
|
Max Display |
4000 |
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
65 x 43mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
370g |
|
Product Size |
180 x 87 x 47mm |
|
Standard Accessories |
Battery, Test Lead, English Manual, Multi-Purpose Socket |
|
Optional Accessories* |
USB Interface Cable |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
20pcs |
|
Standard Carton Measurement |
465 x 335 x 345mm (0.054 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
12kg |
|
|
SRT61B |
SRT61B Modern Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
40mV/400mV/4V/40V/400V/1000V |
±(0.5%+1) |
|
AC Voltage |
40mV/400mV/4V/40V/400V/750V |
±(1.0%+3) |
|
AC Current |
400mA/4000mA/40mA/400mA/4A/10A |
±(1.2%+5) |
|
DC Current |
400mA/4000mA/40mA/400mA/4A/10A |
±(1.0%+2) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
±(1.0%+2) |
|
Capacitance |
40nF/400nF/4mF/40mF/400mF/4000mF |
±(3.0%+5) |
|
Frequency |
10Hz-10MHz |
±(0.1%+4) |
|
Frequency Response |
0 |
45~400Hz |
|
Duty Cycle |
0.1%~99.9% |
Yes |
|
Temperature (°C) |
-40°C~1000°C |
±(1.2%+3) |
|
Temperature (°F) |
-40°F~1832°F |
±(1.2%+4) |
|
Special Functions |
|
|
|
Auto/Manual Ranging |
|
Yes |
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Data Hold |
|
Yes |
|
Max/Min Mode |
|
Yes |
|
Display Backlight |
|
Yes |
|
REL |
|
Yes |
|
Sleep Mode |
Around 15 Minutes |
Yes |
|
Analogue Bar Graph |
41 |
Yes |
|
RS232 (USB) |
|
Yes |
|
Input Protection |
|
Yes |
|
Input Impedance for DC Voltage Measurement |
Around 10MΩ |
Yes |
|
Low Battery Display |
≤7.5V |
Yes |
|
Max Display |
4000 |
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
65 x 43mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
370g |
|
Product Size |
180 x 87 x 47mm |
|
Standard Accessories |
Battery, Test Lead, English Manual, Multi-Purpose Socket
RS232 Interface Cable, Software, Point Contact Temperature
Proble |
|
Optional Accessories* |
USB Interface Cable |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
20pcs |
|
Standard Carton Measurement |
465 x 335 x 345mm (0.054 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
12kg |
|
|
SRT61C |
SRT61C Modern Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
60mV/600mV/6V/60V/600V/1000V |
±(0.5%+1) |
|
AC Voltage |
60mV/600mV/6V/60V/600V/750V |
±(1.0%+3) |
|
AC Current |
600mA/6000mA/60mA/600mA/6A/10A |
±(1.2%+5) |
|
DC Current |
600mA/6000mA/60mA/600mA/6A/10A |
±(1.0%+3) |
|
Resistance |
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ |
±(1.0%+2) |
|
Capacitance |
40nF/400nF/4mF/40mF400mF/4000mF |
±(3.0%+5) |
|
Frequency |
10Hz-10MHz |
±(0.1%+4) |
|
Frequency Response |
0 |
45Hz~1kHz |
|
Duty Cycle |
0.1%~99.9% |
Yes |
|
Temperature (°C) |
-40°C~1000°C |
±(1.2%+3) |
|
Temperature (°F) |
-40°F~1832°F |
±(1.2%+4) |
|
Special Functions |
|
|
|
Auto/Manual Ranging |
|
Yes |
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Data Hold |
|
Yes |
|
Max/Min Mode |
|
Yes |
|
Display Backlight |
|
Yes |
|
REL |
|
Yes |
|
Sleep Mode |
Around 15 Minutes |
Yes |
|
Analogue Bar Graph |
|
61 |
|
RS232(USB) |
|
Yes |
|
Input Protection |
|
Yes |
|
Input Impedance for DC Voltage Measurement |
Around 10MΩ |
Yes |
|
Low Battery Display |
≤7.5V |
Yes |
|
Max Display |
|
6000 |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
65 x 43mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
370g |
|
Product Size |
180 x 87 x 47mm |
|
Standard Accessories |
Battery, Test Lead, English Manual, Multi-Purpose Socket, RS232
Interface Cable,Software, Point Contact Temperature Probe |
|
Optional Accessories* |
USB Interface Cable |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
20pcs |
|
Standard Carton Measurement |
465 x 335 x 345mm (0.054 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
12kg |
|
|
SRT61D |
SRT61D Modern Digital Multimeters
|
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
60mV/600mV/6V/60V/600V/1000V |
±(0.5%+1) |
|
AC Voltage |
60mV/600mV/6V/60V/600V/750V |
±(1.0%+3) |
|
AC Current |
600mA/6000mA/60mA/600mA/6A/10A |
±(1.2%+5) |
|
DC Current |
600mA/6000mA/60mA/600mA/6A/10A |
±(1.0%+3) |
|
Resistance |
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ |
±(1.0%+2) |
|
Capacitance |
40nF/400nF/4mF/40mF/400mF/4000mF |
±(3.0%+5) |
|
Frequency |
10Hz-10MHz |
±(0.1%+4) |
|
Frequency Response |
0 |
45Hz~3kHz |
|
Duty Cycle |
0.1%~99.9% |
Yes |
|
Special Functions |
|
|
|
Auto/Manual Ranging |
|
Yes |
|
Diode |
|
Yes |
|
True RMS |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Data Hold |
|
Yes |
|
Max/Min Mode |
|
Yes |
|
Display Backlight |
|
Yes |
|
REL |
|
Yes |
|
Analogue Bar Graph |
|
61 |
|
RS232 (USB) |
|
Yes |
|
Input Protection |
|
Yes |
|
Input Impedance for DC Voltage Measurement |
Around 10MΩ |
Yes |
|
Low Battery Display |
≤7.5V |
Yes |
|
Max Display |
|
6000 |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
65 x 43mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
370g |
|
Product Size |
180 x 87 x 47mm |
|
Standard Accessories |
Battery, Test Lead, English Manual,
Multi-Purpose Socket, RS232 Interface
Cable,Software |
|
Optional Accessories* |
USB Interface Cable |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
20pcs |
|
Standard Carton Measurement |
465 x 335 x 345mm (0.054 CBM Per Standard
Carton) |
|
Standard Carton Gross Weight |
12kg |
|
|
|
|
SRT61E |
|
SRT61E Modern Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
220mV/2.2V22V220V/1000V |
±(0.1%+2) |
|
AC Voltage |
220mV/2.2V/22V/220V/750V |
±(0.8%+10) |
|
AC Current |
220mA/2200mA/22mA/220mA/2.2A/10A |
±(0.8%+10) |
|
DC Current |
220mA/2200mA/22mA/220mA/2.2A/10A |
±(0.5%+10) |
|
Resistance |
220Ω/2.2KΩ/22kΩ/220kΩ/2.2MΩ/22MΩ/220MΩ |
±(0.5%+10) |
|
Capacitance |
22nF/220nF/2.2mF/22mF/220mF/
2.2mF/22mF/220mF |
±(3.0%+5) |
|
Frequency |
10Hz-220MHz |
±(0.01%+5) |
|
Frequency Response |
0 |
45Hz~10kHz |
|
Duty Cycle |
0.1%~99.9% |
Yes |
|
Special Functions |
|
|
|
Auto/Manual Ranging |
|
Yes |
|
Diode |
|
Yes |
|
True RMS
|
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Data Hold |
|
Yes |
|
Peak Value |
|
Yes |
|
Display Backlight |
|
Yes |
|
REL |
|
Yes |
|
Sleep Mode |
Around 15 Minutes |
Yes |
|
Analogue Bar Graph |
|
46 |
|
RS232 (USB) |
|
Yes |
|
Input Protection |
|
Yes |
|
Input Impedance for DC Voltage Measurement
|
Around 10MΩ |
Yes |
|
Low Battery Display |
≤7.5V |
Yes |
|
Max Display |
|
22000 |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
65 x 43mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
370g |
|
Product Size |
180 x 87 x 47mm |
|
Standard Accessories |
Battery, Test Lead, English Manual,
Multi-Purpose Socket, RS232 Interface
Cable,Software |
|
Optional Accessories* |
USB Interface Cable |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
20pcs |
|
Standard Carton Measurement |
465 x 335 x 345mm (0.054 CBM Per Standard
Carton) |
|
Standard Carton Gross Weight |
12kg |
|
|
|
|
SRT533 |
SRT533
Insulation Resistance
Multimeters
|
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
Insulation
Resistance
Measurement
|
50V: 0.1MΩ ~
50.0MΩ
100V: 0.1MΩ ~
100.0MΩ |
±(3%+5)
±(3%+5) |
|
250V: 0.2MΩ ~
99.9MΩ
100MΩ~250MΩ |
±(3%+5)
±(3%+5) |
|
500V: 0.5MΩ ~
99.9MΩ
100MΩ~500MΩ |
±(3%+5)
±(3%+5) |
|
1000V: 4.0MΩ ~
99.9MΩ
100MΩ~999MΩ |
±(3%+5)
±(3%+5) |
|
1.00GΩ
~ 2.00GΩ
|
±(5%+5) |
|
DC Voltage
Measurement |
60mV/600mV/6V/60V/600V/1000V |
±(0.09%+6) |
|
AC Voltage
Measurement |
6V/60V/600V/1000V |
±(1%+3) |
|
DC Current
Measurement |
60mA/600mA |
±(1.0%+2) |
|
AC Current
Measurement |
60mA/600mA |
±(1.5%+2) |
|
Resistance
Measurement |
600Ω/6KΩ/60KΩ/600KΩ/6MΩ/40MΩ |
±(0.9%+2) |
|
Capacitance
Measurement |
10nF/100nF/1μF/10μF/100μF |
±(3%+5) |
|
Frequency
Measurement |
60Hz/600Hz/6KHz/60KHz/600KHz/1MHz |
±(0.1%+3) |
|
Temperature
Testing
|
-40°C ~ 537°C
-40°F ~ 998 °F |
±(1%+10)
±(1%+10) |
|
Special
Functions |
|
|
|
Auto Ranging |
|
Yes |
|
Diode |
|
Yes |
|
Continuity
Buzzer |
|
Yes |
|
True RMS |
|
Yes |
|
Data Hold |
|
Yes |
|
Data Logging |
|
99 |
|
Full Icon
Display |
|
Yes |
|
Display
Backlight |
|
Yes |
|
Max / Min Mode |
|
Yes |
|
Memory Zeroing
|
|
Yes |
|
Sleep Mode |
|
Yes |
|
Low Battery
Display |
|
Yes |
GENERAL CHARACTERISTICS
|
Power |
1.5V Battery× 6 |
|
LCD Size |
81 × 46mm |
|
Product Color |
Red and Grey |
|
Product Net
Weight |
505g |
|
Product Size |
97 × 203 × 46mm |
|
Standard
Accessories |
Battery, Test
Lead, English
Manual,
Alligator Clip,
Point Contact
Temperature
Probe, Carrying
Bag |
|
Standard
Individual
Packing |
Gift Box |
|
Standard
Quantity Per
Carton |
20pcs |
|
Standard Carton
Measurement |
460 × 310 ×
368mm (0.053CBM
Per Standard
Carton) |
|
Standard Carton
Gross Weight |
12kg |
|
|
|
|
|
|
SRT71A |
SRT71A Intelligent Digital Multimeters
|
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.1%+8) |
|
AC Voltage |
2V/20V/200V/1000V |
±(0.8%+40) |
|
ACBandwidh |
100KHz |
Yes |
|
DC Current
|
200µA/2000µA/20A/200mA/10A |
±(0.2%+20) |
|
AC Current |
200µA/2000µA/20A/200mA/10A |
±(1%+15) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ |
±(0.5%+20) |
|
Capacitance |
20nF/200nF/2µF/20µF/200µF/2mF/20mF |
±(1.5%+20) |
|
Frequency |
20Hz/200Hz/2kHz/20kHz/200KHz/
2MHz/20MHz/200MHz |
±(0.1%+15) |
|
Duty Cycle
|
10%~90% |
±(1%+30) |
|
4~20mA Loop |
0%~100% |
±(1%+50) |
|
Special Functions |
|
|
|
Fused 10A Range |
|
Yes |
|
Auto Ranging
|
|
Yes |
|
Current Measurement
Alarm |
|
Yes |
|
Function Set Up |
|
Yes |
|
Votage & Current :
AC + DC Measurement |
|
Yes |
|
Diode
|
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
True RMS |
|
Yes |
|
Peak Hold
|
|
Yes |
|
Max/Min Mode
|
|
Yes |
|
Relative Mode
|
|
Yes |
|
Data Hold
|
|
Yes |
|
USB |
|
Yes |
|
Double Display
Backlight |
|
Yes |
|
Full lcon Disply
|
|
Yes |
|
Sleep Mode
|
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for
DC Voltage Measurement |
DC 200mV: Around
2.5GΩ
All Other Ranges: 10MΩ |
Yes |
|
Max. Display
|
20000 |
Yes |
|
Analogue Bar Graph |
|
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
73 x 50mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
384g |
|
Product Size |
200 x 93 x 40mm |
|
Standard Accessories |
Test Lead, Battery,
English Manual, Alligator Clip,
Test Clip, USB Interface Cable, Software,
Carrying Bag |
|
Standard Individual
Packing |
Gift Box
|
|
Standard Quantity
Per Carton |
20pcs |
|
Standard Carton
Measurement |
530 x 360 x 385mm
(0.073 CBM Per Standard Carton) |
|
Standard Carton
Gross Weight |
22kg |
|
|
|
|
 |
SRT71B Intelligent Digital Multimeters
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.05%+5) |
|
AC Voltage |
2V/20V/200V/1000V |
±(0.6%+40) |
|
AC Bandwidth
|
100KHz |
Yes |
|
DC Current |
200µA/2000µA/20A/200mA/10A |
±(0.15%+20) |
|
AC Current |
200µA/2000µA/20A/200mA/10A |
±(0.8%+15) |
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/
2MΩ/20MΩ |
±(0.4%+20) |
|
Capacitance |
20nF/200nF/2µF/20µF/200µF/
2mF/20mF |
±(1.2%+20) |
|
Temperature(°C) |
-40°C~1000°C |
±(1%+30) |
|
Temperature(°F) |
-40°F~1832°F |
±(1.5%+50) |
|
Frequency |
20Hz/200Hz/2kHz/20kHz/200KHz
/2MHz/20MHz/200MHz |
±(0.1%+15) |
|
Duty Cycle
|
10%~90% |
±(1%+30) |
|
Special Functions |
|
|
|
Fused 10A Range |
|
Yes |
|
Auto Ranging
|
|
Yes |
|
Current Measurement Alarm |
|
Yes |
|
Function Set Up |
|
Yes |
|
Voltage & Current :
AC + DC Measurement |
|
Yes |
|
Data Logging |
|
100 |
|
Data Recall
|
|
Yes |
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
True RMS |
|
Yes |
|
Peak Hold |
|
Yes |
|
Max/Min Mode
|
|
Yes |
|
Relative Mode
|
|
Yes |
|
Data Hold
|
|
Yes |
|
USB |
|
Yes |
|
Double Display Backlight |
|
Yes |
|
Full lcon Display
|
|
Yes |
|
Sleep Mode
|
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for
DC Voltage Measurement |
DC 200mV : Around 2.5GΩ
All Other Ranges : 10MΩ |
Yes |
|
Max. Display |
20000 |
Yes |
|
Analogue Bar Graph |
|
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
73 x 50mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
384g |
|
Product Size |
200 x 93 x 40mm |
|
Standard Accessories |
Test Lead, Battery,
English Manual, Point Contact Temperature Probe,
Alligator Clip, Test Clip, USB Interface Cable, Software,
Carrying Bag |
|
Standard Individual
Packing |
Gift Box |
|
Standard Quantity Per
Carton |
20pcs |
|
Standard Carton
Measurement |
530 x 360 x 385mm
(0.073 CBM Per Standard Carton) |
|
Standard Carton Gross
Weight |
22kg |
|
|
SRT71D |
SRT71D Intelligent Digital Multimeter
|
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
400mV/4V/40V/400V/1000V |
±(0.025%+5) |
|
AC Voltage |
4V/40V/400V/1000V |
±(0.4%+30) |
|
AC Bandwidth |
100KHz |
Yes |
|
DC Current |
400µA/4000µA/40A/400mA/10A |
±(0.08%+8) |
|
AC Current |
400µA/4000µA/40A/400mA/10A |
±(0.5%+15) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
±(0.3%+8) |
|
Capacitance |
40nF/400nF/4µF/40µF/400µF/4mF/40mF |
±(1%+20) |
|
Temperature (°C) |
-40°C ~ 1000°C |
±(1%+30) |
|
Temperature (°F) |
-40°F ~ 1832°F |
±(1.5%+50) |
|
Frequency |
40Hz/400Hz/4kHz/40kHz/
400kHz/4MHz/40MHz/400MHz |
±(0.01%+8) |
|
Duty Cycle |
10%~90% |
±(1%+30) |
|
4~20mA Loop |
0~100% |
±(1%+50) |
|
Special Functions |
|
|
|
Fused 10A Range |
|
Yes |
|
Auto Ranging |
|
Yes |
|
Current Measurement Alarm |
|
Yes |
|
Function Set Up |
|
Yes |
|
Auto Ranging |
|
Yes |
|
Votage & Current :
AC + DC Measurement |
|
Yes |
|
Data Logging |
|
9999 |
|
Data Recall |
|
Yes |
|
Diode |
|
Yes |
|
Continuity Buzzer
|
|
Yes |
|
True RMS
|
|
Yes |
|
Peak Hold |
|
Yes |
|
Max/Min Mode |
|
Yes |
|
Relative Mode
|
|
Yes |
|
Data Hold |
|
Yes |
|
USB |
|
Yes |
|
Double Display Backlight |
|
Yes |
|
Full Icon Display |
|
Yes |
|
Sleep Mode |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Input Impedance for
DC Voltage Measurement |
DC 200mV : Around 2.5GΩ
All Other Ranges : 10MΩ |
Yes |
|
Max. Display |
40000 |
Yes |
|
Analogue Bar Graph |
|
Yes |
GENERAL CHARACTERISTICS
|
Power |
9V Battery (6F22) |
|
LCD Size |
73 x 50 mm |
|
Product Colour |
Red and Grey |
|
Product Net Weight |
384g |
|
Product Size |
200 x 93 x 40mm |
|
Standard Accessories |
Test Lead, English Manual,
Battery, Alligator Clip, USB
Interface Cable,
Software, Point Contact
Temperature, Probe, Carrying
Bag, Test Clip |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
20 pcs |
|
Standard Carton Measurement |
542 x 376 x 388mm (0.079 CBM Per
Standard Carton) |
|
Standard Carton Gross Weight |
18kg |
|
|
|
|
|
|
Features:
1. Adjustable data recording interval
2. True RMS, duty cycle, continuity buzzer
3. MAX/MIN/REL modes; peak/data hold; analog bar graph
4. Measure AC and DC at the same time (dual display)
5. 4-20mA loop test
6. 45Hz~100kHz frequency response
7. LCD backlight; misplug alarm
8. Auto power off, low battery indication
9. Data logging
10. Auto and manual ranges selectable
11. USB interface, Bluetooth
12. 2500W power measurement
13. Temperature measurement, k-type
14. Smart phone APP: iDMM
15. Works with UT-D07A Bluetooth adaptor
16. Download from Apple Store or Google Play Store |
SRT71E Intelligent
Digital Multimeter
Specifications
|
Basic Functions |
Range |
Accuracy |
|
DC voltage (V) |
1000V |
±(0.025%+5) |
|
AC voltage (V) |
1000V |
±(0.4%+30) |
|
DC current (A) |
10A |
±(0.1%+15) |
|
AC current (A) |
10A |
±(0.7%+15) |
|
Resistance (Ω) |
40MΩ |
±(0.3%+8) |
|
Capacitance (F) |
40mF |
±(1%+20) |
|
Frequency (Hz) |
40Hz~400MHz |
±(0.01%+8) |
|
Temperature |
-40°C~1000°C |
±(1%+30) |
|
-40°F~1832°F |
±(1.5%+50) |
|
Display count |
40000 |
|
General Characteristics |
|
Power |
9V battery (6F22) |
|
Display |
73mm x 50mm |
|
Product color |
Red and grey |
|
Product net weight |
384g |
|
Product size |
200mm x 93mm x 40mm |
|
Standard accessories |
Battery, test leads, alligator clip, test clips,
USB interface cable, PC software CD, carrying bag, point contact
temperature probe, power adaptor |
|
Standard individual packing |
Gift box, English manual |
|
Standard quantity per carton |
10pcs |
|
Standard carton measurement |
540mm x 360mm x 275mm |
|
Standard carton gross weight |
12.5kg |
|
|
Product introduction:
SRT139 series are CAT III 600V digital multimeters designed for
electricians. Its NCV feature can effectively check electrical status
through measuring EM field intensity.
Features:
1. MAX/MIN/REL modes
2. Data hold, LED backlight, auto power off
3. Full range protection (600V)
4. True RMS
5. NCV
6. Auto/manual ranges selectable |
SRT139C
True RMS Digital Multimeter
Specifications
|
Basic Functions |
Range |
Accuracy |
|
DC voltage (V) |
600V |
±(0.5%+2) |
|
AC voltage (V) |
600V |
±(0.8%+3) |
|
DC current (A) |
10A |
±(0.7%+2) |
|
AC current (A) |
10A |
±(1%+3) |
|
Resistance (Ω) |
60MΩ |
±(0.8%+2) |
|
Capacitance (F) |
99.99mF |
±(4%+5) |
|
Frequency (Hz) |
10Hz~10MHz |
±(0.1%+4) |
|
Temperature (°C) |
-40°C~1000°C |
±(1%+3) |
|
Temperature (°F) |
-40°F~1832°F |
±(1.5%+5) |
|
Features |
|
Display count |
6000 |
|
Auto range/ Manual range/ True RMS |
Yes |
|
Bandwidth (Hz) |
45Hz~1kHz |
|
NCV/Continuity buzzer |
Yes |
|
Duty cycle |
0.1%~99.9% |
|
Diode |
Around 3V |
|
General Characteristics |
|
Power |
1.5V battery (R6) x 2 |
|
Display |
58mm x 36mm |
|
Product color |
Red and grey |
|
Product net weight |
354g |
|
Product size |
170mm x 80mm x 48mm |
|
Standard accessories |
Batteries, test leads, temperature probe |
|
Standard individual packing |
Gift box, English manual |
|
Standard quantity per carton |
20pcs |
|
Standard carton measurement |
450mm x 330mm x 340mm |
|
Standard carton gross weight |
12.2kg |
|
Optional accessory |
Current sensor AC/DC 40A |
|
|
SRT81B |
SRT81B Scope
Digital Multimeter
SPECIFICATIONS
|
Basic Functions |
Range |
Best Accuracy |
|
DC Voltage |
400mV/4V/40V/400V/1000V |
±(0.8%+8) |
|
AC Voltage |
4V/40V/400V/750V |
±(1%+15) |
|
DC Current |
400mA /4000mA/40mA/400mA/4A/10A |
±(1%+8) |
|
AC Current |
400mA/4000mA/40mA/400mA/4A/10A |
±(1.5%+8) |
|
Resistance |
400Ω/ 4kΩ/40kΩ/400kΩ/4MΩ/ 40MΩ |
±(1%+5) |
|
Capacitance |
40nF /400nF/4mF/40mF/100mF |
±(3%+8) |
|
Frequency |
10Hz~10MHz |
±(0.1%+3) |
|
Vertical Accuracy |
|
±(5%+1) |
|
Input Sensitivity |
20mV/div-500V/div (1-2-5) |
Yes |
|
Horizontal Accuracy |
|
±(0.01%+1) |
|
Timebase Range |
100ns/div-5s/div (1-2-5) |
Yes |
|
Bandwidth |
|
8MHz |
|
Display Resolution |
160X160 |
Yes |
|
Real-Time Sample Rate |
|
40MSa/s |
|
Duty Cycle |
0.1%~99.9% |
Yes |
|
Special Functions |
|
|
Diode |
|
Yes |
|
Continuity Buzzer |
|
Yes |
|
Display |
160x160 Monochrome |
Yes |
|
Trigger Types |
Free Run / Normal / Single Shot |
Yes |
|
Memory |
10 screens and setups |
Yes |
|
Contrast and Bright Setup |
|
Yes |
|
Input Impedance For DCVoltage Measurement |
Around 10MΩ |
Yes |
|
Sleep Mode |
|
Yes |
|
Low Battery Display |
|
Yes |
|
Display Backlight |
|
Yes |
|
USB |
|
Yes |
|
Max.Display |
3999 |
Yes |
GENERAL CHARACTERISTICS
|
Power |
1.5V Battery (R6) x 6 |
|
LCD Size |
60 x 60mm |
|
Product Color |
Red and Grey |
|
Product Net Weight |
498g |
|
Product Size |
200 x100 x 48mm |
|
Standard Accessories |
Test Lead , Battery, English Manual ,Alligator
Clip、
USB Interface Cable, Software, Power Adapter |
|
Optional Accessories* |
Scope Probe, BNC Probe |
|
Standard Individual Packing |
Gift Box |
|
Standard Quantity Per Carton |
20pcs |
|
Standard Carton Measurement |
490 x 385 x 510mm (0.096 CBM Per Standard
Carton) |
|
Standard Carton Gross Weight |
24kg |
|
|
|
|
|
|
